Infineon英飛凌IPM智能功率模塊
發布時間：2024-01-29 11:49:17 瀏覽：3164
基于不同半導體技術、采用不同封裝、適用不同電壓和電流等級的IPM智能模塊，分為緊湊型系列、標準系列和高性能系列。我們的IPM智能模塊系列包括 CIPOS?
Nano、CIPOS ? Micro、CIPOS ? Mini和CIPOS?
Maxi等。這些高能效智能功率模塊IGBT集成了最先進的功率半導體和IC技術。
這些智能功率模塊能效高，集成了新功率半導體和控制芯片技術，并運用了英飛凌先進的IGBT、MOSFET、新一代柵極驅動
IC和新型熱機械技術。通過提高功率密度、增強系統耐用性和可靠性，該系列模塊有效提升了系統性能和能效。
產品選型：
| Product | Package | Product Group | Voltage Class [V] | Switch Type | Pmot 10kHz [W] | Rated Current [A] |
| IM818-LCC | DIP 36x23D | CIPOS? Maxi | 1200 | IGBT | 3 | 15 |
| IM818-MCC | DIP 36x23D | CIPOS? Maxi | 1200 | IGBT | 2.2 | 10 |
| IM818-SCC | DIP 36x23D | CIPOS? Maxi | 1200 | IGBT | 1.4 | 5 |
| IM828-XCC | DIP 36x23D | CIPOS? Maxi | 1200 | CoolSiC? | 4.8 | 20 |
| IM241-L6S1B | SOP 29x12 | CIPOS? Micro | 600 | IGBT | 450 | 6 |
| IM241-L6T2B | DIP 29x12 | CIPOS? Micro | 600 | IGBT | 450 | 6 |
| IM241-M6S1B | SOP 29x12 | CIPOS? Micro | 600 | IGBT | 325 | 4 |
| IM241-M6S1J | SOP 29x12 | CIPOS? Micro | 600 | IGBT | 325 | 4 |
| IM241-M6T2B | DIP 29x12 | CIPOS? Micro | 600 | IGBT | 325 | 4 |
| IM241-M6T2J | DIP 29x12 | CIPOS? Micro | 600 | IGBT | 325 | 4 |
| IM241-S6S1B | SOP 29x12 | CIPOS? Micro | 600 | IGBT | 200 | 2 |
| IM241-S6S1J | SOP 29x12 | CIPOS? Micro | 600 | IGBT | 200 | 2 |
| IM241-S6T2B | DIP 29x12 | CIPOS? Micro | 600 | IGBT | 200 | 2 |
| IM241-S6T2J | DIP 29x12 | CIPOS? Micro | 600 | IGBT | 200 | 2 |
| IFCM20T65GD | DIP 36x21D | CIPOS? Mini | 650 | IGBT | 3600 | 20 |
| IFCM20U65GD | DIP 36x21D | CIPOS? Mini | 650 | IGBT | 4400 | 20 |
| IFCM30T65GD | DIP 36x21D | CIPOS? Mini | 650 | IGBT | 5400 | 30 |
| IFCM30U65GD | DIP 36x21D | CIPOS? Mini | 650 | IGBT | 6400 | 30 |
| IFCM10P60GD | DIP 36x21D | CIPOS? Mini | 600 | IGBT | 1200 | 10 |
| IFCM10S60GD | DIP 36x21D | CIPOS? Mini | 600 | IGBT | 1200 | 10 |
| IFCM15P60GD | DIP 36x21D | CIPOS? Mini | 600 | IGBT | 1800 | 15 |
| IFCM15S60GD | DIP 36x21D | CIPOS? Mini | 600 | IGBT | 1800 | 15 |
| IGCM04F60GA | DIP 36x21 | CIPOS? Mini | 600 | IGBT | 600 | 4 |
| IGCM04G60GA | DIP 36x21 | CIPOS? Mini | 600 | IGBT | 600 | 4 |
| IGCM06F60GA | DIP 36x21 | CIPOS? Mini | 600 | IGBT | 800 | 6 |
| IGCM06G60GA | DIP 36x21 | CIPOS? Mini | 600 | IGBT | 800 | 6 |
| IGCM10F60GA | DIP 36x21 | CIPOS? Mini | 600 | IGBT | 1000 | 10 |
| IGCM15F60GA | DIP 36x21 | CIPOS? Mini | 600 | IGBT | 1200 | 15 |
| IGCM20F60GA | DIP 36x21 | CIPOS? Mini | 600 | IGBT | 1600 | 20 |
| IKCM10H60GA | DIP 36x21 | CIPOS? Mini | 600 | IGBT | 1000 | 10 |
| IKCM10L60GA | DIP 36x21 | CIPOS? Mini | 600 | IGBT | 1200 | 10 |
| IKCM15F60GA | DIP 36x21 | CIPOS? Mini | 600 | IGBT | 1600 | 15 |
| IKCM15H60GA | DIP 36x21 | CIPOS? Mini | 600 | IGBT | 1200 | 15 |
| IKCM15L60GA | DIP 36x21 | CIPOS? Mini | 600 | IGBT | 1600 | 15 |
| IKCM15L60GD | DIP 36x21D | CIPOS? Mini | 600 | IGBT | 2200 | 15 |
| IKCM20L60GA | DIP 36x21 | CIPOS? Mini | 600 | IGBT | 1800 | 20 |
| IKCM20L60GD | DIP 36x21D | CIPOS? Mini | 600 | IGBT | 2400 | 20 |
| IKCM20R60GD | DIP 36x21D | CIPOS? Mini | 600 | IGBT | 2400 | 20 |
| IKCM30F60GA | DIP 36x21 | CIPOS? Mini | 600 | IGBT | 2000 | 30 |
| IKCM30F60GD | DIP 36x21D | CIPOS? Mini | 600 | IGBT | 2600 | 30 |
| IM523-L6A | DIP 36x21 | CIPOS? Mini | 600 | IGBT | 1200 | 15 |
| IM523-M6A | DIP 36x21 | CIPOS? Mini | 600 | IGBT | 800 | 10 |
| IM523-S6A | DIP 36x21 | CIPOS? Mini | 600 | IGBT | 600 | 6 |
| IM523-X6A | DIP 36x21 | CIPOS? Mini | 600 | IGBT | 1400 | 17 |
| IM535-U6D | DIP 36x21D | CIPOS? Mini | 600 | IGBT | 3000 | 30 |
| IM564-X6D | DIP 36x21D | CIPOS? Mini | 600 | IGBT | 2400 | 20 |
| IGCM04G60HA | DIP 36x21 | CIPOS? Mini | 600 | IGBT | 600 | 4 |
| IKCM15R60GD | DIP 36x21D | CIPOS? Mini | 600 | IGBT | 2200 | 15 |
| IM111-X6Q1B | QFN 12x10 | CIPOS? Nano | 600 | CoolMOS? | 200 | 2 |
| IRSM807-045MH | QFN 8x9 | CIPOS? Nano | 500 | MOSFET | 130 | 4 |
| IRSM807-105MH | QFN 8x9 | CIPOS? Nano | 500 | MOSFET | 200 | 10 |
| IRSM808-105MH | QFN 8x9 | CIPOS? Nano | 500 | MOSFET | 200 | 10 |
| IRSM836-025MA | QFN 12x12 | CIPOS? Nano | 500 | MOSFET | 55 | 2 |
| IRSM836-035MA | QFN 12x12 | CIPOS? Nano | 500 | MOSFET | 70 | 3 |
| IRSM836-035MB | QFN 12x12 | CIPOS? Nano | 500 | MOSFET | 70 | 3 |
| IRSM836-045MA | QFN 12x12 | CIPOS? Nano | 500 | MOSFET | 80 | 4 |
| IM111-X3Q1B | QFN 12x10 | CIPOS? Nano | 250 | OptiMOS? | 200 | 4 |
| IRSM808-204MH | QFN 8x9 | CIPOS? Nano | 250 | MOSFET | 200 | 20 |
| IRSM836-024MA | QFN 12x12 | CIPOS? Nano | 250 | MOSFET | 40 | 2 |
| IRSM836-044MA | QFN 12x12 | CIPOS? Nano | 250 | MOSFET | 60 | 4 |
| IRSM836-084MA | QFN 12x12 | CIPOS? Nano | 250 | MOSFET | 85 | 7 |
| IRSM005-301MH | QFN 7x8 | CIPOS? Nano | 100 | MOSFET | 165 |
|
| IRSM005-800MH | QFN 7x8 | CIPOS? Nano | 40 | MOSFET | 165 | 80 |
| IRSM836-015MA | QFN 12x12 | CIPOS? Nano | 500 | MOSFET | 50 | 1 |
| IM323-L6G | DIP 33x19 | CIPOS? Tiny | 600 | IGBT | 1200 | 15 |
| IM323-L6G2 | DIP 33x19 | CIPOS? Tiny | 600 | IGBT | 1200 | 15 |
